Straight Knife Cutting Machine
Product Details:
Product Description
Product Description : With versatility unmatched by any other straight knife available, the Blue Streak II is the obvious choice when one machine is required to perform many roles, designed with a low center of gravity for ease of handling, and featuring the best power to weight ratio in the industry, the Blue Streak II provides maximum productivity with minimal fatigue.
Edges:-
Fine Edge: Streak through silk, synthetic blends, knits, loosely wooven cloth, high pile fabric quilting.
Medium Edge: Shears through cotton, light wool, polyster, men's suiting, velvetten.
Coarse Edge: Slices through heavier weight of cotton and wool, twil tightly woven cloth, lining prewashed denim, outwear, soft leather vinyl, rubberrized material.
Motors: Available with 1 Phase Motor of 110 V and 220 V & with 3 Phase Motor of 220 V and 380 V.
Speed: With Single / Dual speed, Variable speed is not available.
Blades: High Speed Steel is standard blade. Optional blade/s are carbon steel, PTFE coated, wave edge, wave groove, rounded tip, angled tip.
Belts: Fine, medium, coarse, rough, waterproof are available.
Weight: 34 lbs; 15.4 kgs.
Horsepower: .65 hp .1 ph & .93 hp .3 ph.
| Blade Size (inch) | : | 5 | 6 | 7 | 8 |
| Blade Size (cm) | : | 12.7cm | 15.2cm | 17.7cm | 20.3cm |
| Cutting Capacity (inch) | : | 31/2 | 41/2 | 51/2 | 61/2 |
| Cutting Capacity (cm) | : | 8.89 cm | 11.4 cm | 13.9 cm | 16.5 cm |
| Stroke Size (inch) | : | 11/8 | 11/8 | 1/4 | 11/4 |
| Stroke Size (cm) | : | 8.89 cm | 8.89 cm | 11.4 cm | 11.4 cm |
